Single Storey, Monopitch House Plan (440sqm)


A Four Bedroom Open-Plan Modern Home Design

The glass link. This home plan consists of two heavy bodies, connected with a light tunnel in the middle, which acts as the core of the home and houses the kitchen, living and dining spaces. The bedrooms are located within these two heavy bodies, allowing for more privacy. The transparent central space spills out onto a deck, expanding the interior out, towards the landscape. An ideal home for a family of four, in need of a generous space that is connected to its landscape.
Features: 4 Bedrooms, 4 Bathrooms, 2 Garages, Open-plan Kitchen, Dining & Living, Scullery, Dry yard, Pool, Covered Patio

Additional information






Garage, Pool

Included in price plan

Digital plans in PDF format (uneditable) of the design which includes:
  • Ground floor plan 1:100
  • Roof plan 1:100
  • Elevations 1:100
  • Sections 1:50
  • Lighting layout 1:100
  • Hot water reticulation and gas layout 1:100
  • Window and door schedule 1:100

Excluded in price plan

  • Professional service to complete and certify Site Development plan and working drawing set for council submission
  • Alterations or additions
  • Electronic format of plans in the form of DWG or Revit
NOTE: Contact NOAH for a quotation to assist with the exclusions at a time-based fee of R650.00 per hour.

Terms & Conditions

  • Read our Terms and Conditions here for more information
  • No refund and no return policy

4 Bedrooms

4 Bathrooms

2 Garages

Open plan kitchen, dining and living
